Cross-platform rendering

PowerBGInfo separates collecting facts, rendering an image, and applying it to a desktop. -Target File generates an image without reading or changing the current wallpaper. It also works on a server or CI host without a graphical session. Supply background dimensions when no monitor geometry is available.

$facts = Get-BGInfoSystemInfo
New-BGInfo -Target File -Theme Graphite -SpaceY 40 -ConfigurationDirectory ([IO.Path]::GetTempPath()) -OutputFileName 'machine.png' {
    New-BGInfoBackground -Width 1920 -Height 1080
    New-BGInfoLabel -Name $facts.ComputerName -FontSize 56
    New-BGInfoValue -Name 'OS' -Value $facts.OSName
    New-BGInfoValue -Name 'Uptime' -Value $facts.UptimeText
    $facts.Disks | New-BGInfoTable -Region Right -Title 'Volumes' -Property Drive, FreeGB, UsedPercent
}

Examples/Run.BGInfo.CrossPlatform.ps1 provides a parameterized version. It renders a file by default; select -Target Wallpaper to apply it deliberately. The sample uses -SpaceY 40 to leave space above the text for a desktop panel. Adjust the spacing and layout for the actual GNOME/KDE panels, docks and chosen wallpaper fit. PowerBGInfo does not discover or automatically avoid those areas; callers must reserve the space their panels occupy.

The CLI accepts the same JSON configuration on every platform and provides --doctor for desktop diagnostics. --no-apply and Invoke-BGInfo -NoApply render file previews even when a saved Windows configuration retains all-user options; those options are inactive for the file target.

Desktop capabilities

Run Get-BGInfoCapability before selecting a desktop target. A successful image render does not establish that a desktop accepted or displayed it.

Desktop application requires the intended user's graphical session and the platform facilities reported by DesktopManager. A system account, SSH session, or administrator token is not a substitute for that session. Unsupported lock-screen or all-user requests fail before rendering or changing wallpaper. Managed-device policies can still deny an otherwise supported operation.

Linux geometry discovery uses an already-installed xrandr; it does not install that utility. Qualified geometry requires one connected X11 output at origin +0+0, without rotation or reflection, with an identity transform, no panning or non-desktop flag, and framebuffer dimensions matching its current native mode. Wayland/XWayland, transformed or multiple-output layouts do not provide qualified geometry. Supply explicit image dimensions and leave screen-coordinate layout disabled when geometry is unavailable. No desktop panel or UI scale is inferred.

Forced refresh temporarily assigns a copy before reassigning the output path. On macOS, those assignments can add entries to Wallpaper settings' photo history even after the temporary file is removed. -DisableWallpaperRefresh uses a single assignment; choose it when the desktop refreshes the updated output path without that workaround.

Display indices describe the current topology. They can change after docking or reconnecting a screen. The monitor output also carries the backend display identity. GNOME's ordinary background setting does not select individual screens; use its desktop target at monitor index zero. KDE uses the addressable wallpaper targets reported by DesktopManager, even when physical geometry is unavailable. A changed activity, target identity or known geometry rejects application of an image generated for the earlier target.

When neither -FilePath nor New-BGInfoBackground selects a base, PowerBGInfo uses the effective desktop image and preserves its native fit. An explicitly bound -WallpaperFit takes precedence. Unknown fit or opacity, unreadable native state and missing geometry required by screen-coordinate layout stop the run before application. Known disabled-image colors and gradients can be reproduced when their color syntax and physical target dimensions are available. Supply an explicit background and dimensions when those metadata are unavailable.

GNOME reports effective image opacity as 1 when an image is enabled and 0 when it is disabled. The retained picture-opacity setting does not change the effective GNOME Shell image opacity. A supported image and known fit can therefore be inherited; disabled-image colors and gradients also require the qualified physical geometry described above. An explicit FilePath or New-BGInfoBackground selects the base deliberately when native source metadata are unsupported or unavailable.

KDE supports the local-file org.kde.image wallpaper path. Dynamic plugins, unresolved or multi-image packages, unresolved background colors, and blurred margins with Fit or Center return Unsupported. Applying an explicit static image deliberately changes the wallpaper source; it does not preserve a dynamic plugin's behavior.

Facts and history

Get-BGInfoSystemInfo preserves its existing properties and adds FactStates, which distinguishes available, unavailable, and unsupported facts. Windows uses the existing WMI/Registry provider; Linux uses platform files and common .NET APIs; macOS uses system APIs. Unix volume identities are mount paths, rather than Windows drive letters.

Windows-specific patch, Defender, and BitLocker facts remain Unknown on Unix. They are not translated into superficially similar platform security states. CollectedAt describes the snapshot time; it does not assert that cached hardware metadata was probed again at that instant.

When a built-in chart metric cannot be collected, PowerBGInfo retains its saved history, omits the current chart, and emits a warning. Historic values are not presented as a new healthy reading. The CLI writes warnings to standard error while keeping the generated image path on standard output.

Images, fonts, and portable configuration

CFX supplies dependency-free raster rendering and supported PNG, JPEG, GIF, BMP, PPM, and TIFF input. Some TIFF variants remain unsupported. An unsupported desktop background, including HEIC, reports an error; it is never silently replaced by a plain backdrop. Choose a supported image or a generated background for portable layouts. A rendered still image does not preserve aerial animation, dynamic wallpaper schedules or all-Spaces assignments.

macOS static checkpoints require an existing PNG, JPEG, BMP, or TIFF source with a known native fit. They capture the active screens' URLs and complete AppKit options. HEIC/aerial selections and unknown fit remain unsupported for checkpoint restoration; restoring those selections needs a separately verified native recovery path. The checkpoint does not enumerate Spaces or detect a Space switch.

With screen-coordinate layout, Fill preserves the source aspect ratio and crops its edges to cover the display; Stretch scales the two axes independently.

Fonts are resolved on the rendering host. Install the same licensed font assets where matching typography is required. Scaling a design does not automatically reflow its content for a portrait or ultrawide display; use regions and suitable panel sizes for those layouts.

Relative paths in JSON accept slash or backslash separators. A Windows-rooted path cannot be used as a local path on macOS/Linux. Use relative paths or platform-local absolute paths instead. Output ownership on Unix preserves case-sensitive file identities. Output paths use the same host-aware rules as input paths, including explicit parent-relative paths.

The output provenance file uses versioned escaped fields so native #, pipe and newline filenames round-trip. Validated older Windows records are migrated on the next write. Unescaped older records on macOS/Linux cannot establish an original image because native filenames can contain their row delimiters. Malformed or ambiguous records stop automatic and in-place reuse, including after a later run records a new image. Choose an explicit original FilePath or Background with a different output path to render safely.

Execution and ownership

PowerBGInfo performs one run. Schedule refreshes in the intended user session using the host's normal scheduling facilities. The CLI's PowerShell authoring process has a 120-second outer deadline, configurable through --script-timeout; data-source deadlines remain separate.

The portable PowerShell 7 payload requires PowerShell 7.4 or later and uses net8.0; Windows PowerShell 5.1 keeps the net472 payload. Windows facts are selected at runtime so the portable payload preserves Windows WMI functionality. NativeAOT validation generates files with --no-apply; it does not qualify desktop changes. Use PowerShell or the managed CLI for Windows desktop application, where legacy COM/history paths remain unqualified under NativeAOT. Package qualification remains distinct from ordinary managed execution.

The source owners are:

• PowerBGInfo: fact providers, bindings, configuration, wallpaper regions, health policy, history, output ownership, and run coordination.
• ChartForgeX: charts, factual blocks, typography, panels, backgrounds, patterns, and image composition.
• DesktopManager: display/session discovery, platform wallpaper APIs, readback, capabilities, and operation results.
• PowerForge: shared build, packaging, generated help, and publishing.

The generator is split into rendering, text, desktop, slideshow, output, and history responsibilities. PowerShell and the CLI call that same engine.
